Specification :
| Model name | XF500mmF5.6 R LM OIS WR | ||
|---|---|---|---|
| Lens configuration | 21 elements in 14 groups (includes 2 super ED and 5 ED elements) | ||
| Focal length (35mm format equivalent) | f=500mm (762mm) | ||
| Angle of view | 3.3° | ||
| Max. aperture | F5.6 | ||
| Min. aperture | F22 | ||
| Aperture control | |||
| Aperture control | Number of blades | 9(rounded diaphragm opening) | |
| Step size | 1/3EV (13stops) | ||
| Minimum focus distance (mesured from focal plane) | 2.75m | ||
| Max. magnification | 0.2x | ||
| External dimensions : Diameter x Length* (approx.) * distance from camera lens mount flange | Φ104.5mmx255.5mm | ||
| Weight* (approx.) * excluding caps, hoods and Tripod collar foot | 1,335g | ||
| Diamètre du filtre | Φ95mm | ||
| Accessories included | Flont lens cap FLCP-95 Rear lens cap RLCP-001 Lens hood Tripod collar foot Lens pouch Shoulder strap | ||
